eventBus

06 Jun 2020 • middleware
  • Eventbus
    • 流程图
    • 创建线程池，初始化eventbus
    • 订阅者循环注册
    • 发布事件 * EventBus.java * javadoc * code * Dispatcher.java * javadoc * code

      Eventbus

      流程图

      eventbus流程图

      创建线程池，初始化eventbus

      @Slf4j
@Configuration
public class EventBusConfig {
  @Bean
  public AsyncEventBus asyncEventBus() {
   log.info("{} start create thread pool executor", this.getClass().getSimpleName());
   ThreadPoolExecutor executor = new ThreadPoolExecutor(10, 20, 10, TimeUnit.SECONDS, new LinkedBlockingQueue<>(1), new NamedThreadFactory("LYW-PUBLISHER"));
   log.info("{} end create thread pool executor, executor = {}", executor.toString());
   log.info("{} start init async event bus", this.getClass().getSimpleName());
   AsyncEventBus asyncEventBus = new AsyncEventBus("LYW-PUBLISHER", executor);
   log.info("{} end init async event bus, asyncEventBus = {}", this.getClass().getSimpleName(), asyncEventBus);
   return asyncEventBus;
  }
}

      订阅者循环注册

      1. 抽象类

      ```java @Slf4j @Component public abstract class AbstractSubscriber { @Autowired private EventBusSubscriber subscriber;

    @PostConstruct private void init() { log.info(“{} init”, this.getClass().getSimpleName()); log.info(“{} start register, {}”, this.getClass().getSimpleName(), this.toString()); subscriber.register(this); log.info(“{} end register, {}”, this.getClass().getSimpleName(), this.toString()); } } ```

2. 调用eventbus注册

@Slf4j
@Component
public class EventBusSubscriber {
    @Autowired
    private AsyncEventBus asyncEventBus;
    public void register(Object object) {
        log.info("{} start register object, object = {}, asyncEventBus = {}", this.getClass().getSimpleName(), object.toString(), asyncEventBus.toString());
        asyncEventBus.register(object);
    }
}

EventBus.java

javadoc

Registers all subscriber methods on {@code object} to receive events.
@param object object whose subscriber methods should be registered.

code
  public void register(Object object) {
    subscribers.register(object);
  }

SubscriberRegistry.java

javadoc

Registers all subscriber methods on the given listener object.

code

```java void register(Object listener) { Multimap<Class<?>, Subscriber> listenerMethods = findAllSubscribers(listener);

for (Map.Entry<Class<?>, Collection<Subscriber>> entry : listenerMethods.asMap().entrySet()) {
  Class<?> eventType = entry.getKey();
  Collection<Subscriber> eventMethodsInListener = entry.getValue();

  CopyOnWriteArraySet<Subscriber> eventSubscribers = subscribers.get(eventType);

  if (eventSubscribers == null) {
    CopyOnWriteArraySet<Subscriber> newSet = new CopyOnWriteArraySet<Subscriber>();
    eventSubscribers =
        MoreObjects.firstNonNull(subscribers.putIfAbsent(eventType, newSet), newSet);
  }

  eventSubscribers.addAll(eventMethodsInListener);
}   } ``` ## 发布事件 ```java @Slf4j @Component public class EventBusPublisher {
@Autowired
private AsyncEventBus asyncEventBus;

public void post(Object event) {
    log.info("start post event = {}", event.toString());
    asyncEventBus.post(event);
    log.info("end post event = {}", event.toString());
} } ``` #### EventBus.java ##### javadoc >**Posts an event to all registered subscribers. This method will return successfully after the event has been posted to all subscribers, and regardless of any exceptions thrown by subscribers.**   >**If no subscribers have been subscribed for {@code event}'s class, and {@code event} is not already a {@link DeadEvent}, it will be wrapped in a DeadEvent and reposted.**   >**@param event event to post.**
code
public void post(Object event) {
    Iterator<Subscriber> eventSubscribers = subscribers.getSubscribers(event);
    if (eventSubscribers.hasNext()) {
      dispatcher.dispatch(event, eventSubscribers);
    } else if (!(event instanceof DeadEvent)) {
      // the event had no subscribers and was not itself a DeadEvent
      post(new DeadEvent(this, event));
    }
  }

Dispatcher.java

javadoc

Implementation of a {@link #legacyAsync()} dispatcher.

code

```java private static final class LegacyAsyncDispatcher extends Dispatcher {

// This dispatcher matches the original dispatch behavior of AsyncEventBus.
//
// We can't really make any guarantees about the overall dispatch order for this dispatcher in
// a multithreaded environment for a couple reasons:
//
// 1. Subscribers to events posted on different threads can be interleaved with each other
//    freely. (A event on one thread, B event on another could yield any of
//    [a1, a2, a3, b1, b2], [a1, b2, a2, a3, b2], [a1, b2, b3, a2, a3], etc.)
// 2. It's possible for subscribers to actually be dispatched to in a different order than they
//    were added to the queue. It's easily possible for one thread to take the head of the
//    queue, immediately followed by another thread taking the next element in the queue. That
//    second thread can then dispatch to the subscriber it took before the first thread does.
//
// All this makes me really wonder if there's any value in queueing here at all. A dispatcher
// that simply loops through the subscribers and dispatches the event to each would actually
// probably provide a stronger order guarantee, though that order would obviously be different
// in some cases.

/**
 * Global event queue.
 */
private final ConcurrentLinkedQueue<EventWithSubscriber> queue =
    Queues.newConcurrentLinkedQueue();

@Override
void dispatch(Object event, Iterator<Subscriber> subscribers) {
  checkNotNull(event);
  while (subscribers.hasNext()) {
    queue.add(new EventWithSubscriber(event, subscribers.next()));
  }

  EventWithSubscriber e;
  while ((e = queue.poll()) != null) {
    e.subscriber.dispatchEvent(e.event);
  }
}

private static final class EventWithSubscriber {
  private final Object event;
  private final Subscriber subscriber;

  private EventWithSubscriber(Object event, Subscriber subscriber) {
    this.event = event;
    this.subscriber = subscriber;
  }
}   } ```
 eventBus  middleware
